Carbide Audio introduces the new Evo update to the Carbide Base audio footer. Far from a simple evolution, every part except for the internal ViscoRing™ was redesigned to further enhance vibration control performance.



Improved Coupling

Improved coupling better allows low amplitude vibrations to pass into the device to be dissipated as heat. The following changes were made to improve coupling:

  • A new austenitic (i.e. non-magnetic) stainless steel section was inserted into the top center upper housing of the footer. The high hardness and inherent damping ability of steel provides an ideal platform for supporting equipment.



  • A ridge was machined into the top section’s perimeter to reduce the surface area that contacts the underside of equipment. Behind the point of a spike tip, the line of a ridge provides the next best coupling interface with the added benefit of improved stability. Spikes are still included to facilitate directing one spike upward for maximum engagement to the bottom of equipment.



  • A larger ridge was machined into the perimeter of the footer’s bottom surface to sufficiently distribute the load for use on hardwood floors.

Updated Lower Isolation Stage

Updates to the lower ball bearing isolation stage better allow small horizontal footer movements in response to low amplitude vibrations – a critical component for the isolation of micro vibrations. The following changes to were made to the lower isolation stage:

  • Twice as many viscoelastic elements are utilized to further improve horizontal damping.



  • The zirconia ball bearings utilized in the lower section are 50% larger in diameter. This minimizes indentation of the flat hardened steel bearing raceways which the bearings roll on, thereby reducing rolling resistance.

Progressive Shape Factor

Our patent pending Progressive Shape Factor technology has further evolved. As the ViscoRing™ bulges under compression, ridges within the housing progressively brace the bulging surfaces more gradually as the load initially increases. This results in better isolation performance when supporting equipment on the lightweight end of the weight range for a given ViscoRing™.



While performance in the critical bass and midrange frequencies is similar, the high frequency performance has improved with the updated Evo version.

Spikes

Carbide Base – Evo Version

Horizontal vibration energy transmitted from a 2-way loudspeaker into a 13.6 kg (30 lbs.) weighted aluminum plate placed on top of the loudspeaker. Measurements were taken with the plate on 4 floor spikes and then with the plate on 4 of the Evo version of the Carbide Base footers. Super Light ViscoRings™ were used. Horizontal acceleration was measured with a ACH-01 sensor, 10 dB gain, using 30 Hz to 10 kHz log swept sine excitation.

A new green Super Light ViscoRing™ is now available. It incorporates a new softer viscoelastic material intended for very light equipment weighing less than 16 kg (35 lbs) when using 4 footers. Damping performance is improved an additional 22% over the already highly damped existing Light ViscoRing™.



Our patent pending use of low shape factor viscoelastic materials combined with the extreme loss factor of the new Super Light ViscoRing™ attains a new benchmark for noise dissipation performance among audio footers.

Llano, TXCarbide Audio has released an updated version of their Carbide Base footer incorporating a new way of mounting to equipment and speakers called Universal Stud System.



The Universal Stud System utilizes standard flat head machine screws rather than the proprietary step studs used by the competition. Most screw thread sizes between #8-32 / M4 and 1/2″-13 / M10 can be used in virtually any length depending on need. Each Carbide Base footer now includes 8 screws in common metric and imperial sizes. The Universal Stud System works by passing the desired machine screw up through the bottom center of the Carbide Base footer. A tapered bore keeps the screw centered and a removable polymer insert is included for use with smaller diameter threads. The screw can be threaded directly into the equipment using the supplied screw driver. Alternatively, the supplied machined stainless steel jam screw can be screwed in behind the screw to secure it in place.



Need a different size thread or a different length? Simply replace the screw with another ANSI B18.6.3 standard flat head machine screw in the desired thread size and length. No need to purchase costly proprietary step studs in order to mount footers to your equipment. Alternatively, the jam bolt can be removed to provide a cavity to captively hold a floor spike from a speaker.



The upper portion utilizes more robust selective bracing of the ViscoRing™ to achieve the desired progressive increase in spring rate without the need of an additional viscoelastic pad. The result is superior isolation performance towards the higher end of the weight range for each ViscoRing™.

Additionally, the lower portion of the Carbide Base footer has been optimized to reduce the total height of the footer by 13% or 8.2 mm (0.33 in). The range of height adjustment has been also been increased by 280% allowing adjustment from a minimum height of 59 mm (2.2 in) to a maximum of 74 mm (2.9 in). The additional height adjustment can aid not just in leveling of equipment, but also for adjusting rake angle or tweeter level height when utilized under loudspeakers.

A new red Super Heavy ViscoRing™ has been added with an effective supporting weight of 361 kg (800 lbs) when used as a set of 4. The Super Heavy utilizes a stiffer formulation more ideal for use under heavy racks or extremely large speakers. The existing black Heavy ViscoRing™ has been reformulated to offer a 10% higher level of damping with a new maximum supporting weight of 128 kg (280 lbs). The increased damping of the Heavy ViscoRing™ improves performance under typical heavy equipment compared to the previous formulation.



All Carbide Base footers now include 3 spikes for optional use on carpeted floors. A single spike can also optionally be threaded into the top of the jam bolt. With this upward facing configuration the spike can directly contact the under side of equipment to improve coupling.


Warning: Attempt to read property "post_title" on null in /home/dh_d326fn/carbide.audio/wp-content/plugins/js_composer/include/helpers/helpers.php on line 60

Llano, TX – Carbide Audio is pleased to announce a partnership with Sound|Kaos of Switzerland to provide a vibration control solution for their award winning line of speakers and subwoofer. Carbide Base footers can now be found as standard equipment under their new flagship LIBER|8 speaker and Gravitas subwoofer.



Sound|Kaos leverages the low frequency vibration isolation and damping performance provided by the patent pending design of Carbide Base footers to deliver new levels of clarity to the mid-range and bass on their innovative designs.
